Horizontal Flow Wrapper
Relevant Instructions
This series are ideal for packaging solid products in the non-foodstuffs sector in general. All product contact parts in stainless steel.
-
Servo motor
1 set -
Touch
Screen -
Powder
Coated
- Ergonomic design and reliability, with easy cleaning and operation.
- Compact design, easy cleaning.
- Individual Center-sealed and End-sealed temperature controller.
- Servo Control.
- Packing speed can be adjusted by users.
- Packing size can be flexibly adjusted, suitable for variety of product.
- Individual cutting position adjustment.
- Touch screen operation interface.
- Powder Coated.
- All surfaces in contact with product are stainless steel SUS#304.
- Automatic Eye-Mark tracking system
- No product no pack function
| Model | TD-300C | TD-400C | TD-500C |
|---|---|---|---|
| Speed (Packs/Min) | 10 - 150 PPM | 10 - 150 PPM | 10 - 120 PPM |
| Machine Size | 320*100*145 cm (L*W*H) | 380*100*161 cm (L*W*H) | 476*110*172 cm (L*W*H) |
| N.W. KG | 750 KG | 900 KG | 1,100 KG |
| Max. Film Width | 400 mm | 500 mm | 700 mm |
| Max. Product Size | 300*140*65 mm (L*W*H) | 300*200*80 mm (L*W*H) | 350*250*100 mm (L*W*H) |
| Min. Product Size | 80*30*10 mm (L*W*H) | 80*45*15 mm (L*W*H) | 100*70*15 mm (L*W*H) |
| Voltage | 220V 1PH | 220V 1PH | 220V 1PH |
- Ergonomic design and reliability, with easy cleaning and operation.
- Compact design, easy cleaning.
- Individual Center-sealed and End-sealed temperature controller.
- Servo Control.
- Packing speed can be adjusted by users.
- Packing size can be flexibly adjusted, suitable for variety of product.
- Individual cutting position adjustment.
- Touch screen operation interface.
- Powder Coated.
- All surfaces in contact with product are stainless steel SUS#304.
- Automatic Eye-Mark tracking system
- No product no pack function
This series are ideal for packaging solid products in the foodstuffs sector in general. Machine cover and all product contact parts in stainless steel or food quality plastics.
This series are ideal for packaging solid products in the foodstuffs sector in general.Easy to use: the machine requires no particular maintenance, and it guarantees
Added to your inquiry
TD-300C／TD-400C／TD-500C
Horizontal Flow Wrapper
